Kingston 4GB, DDR4, 2666MHz (PC4-21300), CL19, DIMM Memory
£26.99
In stock
Only 5 left
SKU
KVR26N19S6/4
Product Details |
|
Capacity | 4GB (1 X 4GB) |
Memory Model | Kingston Value RAM |
Bus Type | PC4-21300 |
Rank | Single Rank |
Memory Type | DDR4 |
Memory Speed | 2666MHz |
Pins | 288-Pins |
Voltage | 1.2V |
Data Integrity Check | Non-ECC Unbuffered |
CAS Latency | CL19 |
Package Weight | 0.025 Kg |
Warranty | Lifetime |
This document describes ValueRAM's KVR26N19S6/4 is a 512M x 64-bit (4GB) DDR4-2666 CL19 SDRAM (Synchronous DRAM), 1Rx16, memory module, based on four 512M x 16-bit FBGA components. The SPD is programmed to JEDEC standard latency DDR4-2666 timing of 19-19-19 at 1.2V. Each 288-pin DIMM uses gold contact fingers.
• Power Supply: VDD = 1.2V Typical
• VDDQ = 1.2V Typical
• VPP = 2.5V Typical
• VDDSPD = 2.2V to 3.6V
• Nominal and dynamic on-die termination (ODT) for data, strobe, and mask signals
• Low-power auto self refresh (LPASR)
• Data bus inversion (DBI) for data bus
• On-die VREFDQ generation and calibration
• Single-rank
• On-board I2 serial presence-detect (SPD) EEPROM
• 8 internal banks; 2 groups of 4 banks each
• Fixed burst chop (BC) of 4 and burst length (BL) of 8 via the mode register set (MRS)
• Selectable BC4 or BL8 on-the-fly (OTF)
• Fly-by topology
• Terminated control command and address bus
• PCB: Height 1.23” (31.25mm)
• RoHS Compliant and Halogen-Free
Refurbished | No |
---|---|
Condition | Brand New |
