Asus WS C422 PRO/SE, Workstation, Intel C422, 2066, ATX, DDR4, 5 x PCIe, Dual M.2, Dual LAN, RGB Lighting

£451.99
Out of stock
SKU
90SW0080-M0EAY0
    Add to Compare Add to Wish List
    Key Features

    Product Details

    Type
    Server / Workstation
    Socket 2066
    Chipset Intel C422
    Maximum Memory 512GB DDR4
    RAM Speed
    2666/2400/2133 MHz
    Memory Type DDR4 (Quad Channel)
    Storage 6 x SATA III
    1 x M.2 x4 (2242/2260/2280/22110) - PCIe
    1 x M.2 x4 (2242/2260/2280) - SATA & PCIe
    1 x U.2
    Graphics Intel HD Graphics
    Multi GPU Support Supports NVIDIA 2-Way SLI
    Supports AMD 3-Way CrossFireX
    Graphics Port 1 x VGA
    1 x HDMI
    1 x DisplayPort 1.2
    Audio
    Realtek® ALC S1220A 8-Channel High Definition Audio CODEC featuring Crystal Sound 3
    USB Port Supported

    2 x USB 3.1 Gen 2 (Type-A & C) , 6 x USB 3.1 Gen 1, 6 x USB 2.0 ,

    1 x USB 3.1 Gen 2 front panel connector

    Internal I/O connectors 1 x Aura Addressable Strip
    1 x AAFP
    1 x Aura RGB Strip
    1 x USB 3.1 Gen 1
    1 x USB 2.0
    2 x M.2
    1 x TPM
    6 x SATA 6Gb/s
    1 x VROC_HW_Key
    2 x CPU Fan
    1 x AIO_PUMP
    1 x Thunderbolt
    1 x 24-pin EATX
    2 x 8-pin ATX 12V
    1 x 5-pin EXT_FAN
    1 x Thermal sensor
    1 x U.2
    3 x System panel
    1 x Front fan
    1 x Rear fan
    1 x COM port
    1 x Aspeed VGA
    1 x USB 3.1 Gen 2 front panel
    1 x CPU_OV
    1 x PUMP Fan
    1x 6-pin ATX 12V
    Back Panel I/o Ports 2 x LAN (RJ45)
    2 x USB 3.1 Gen 2 A & C
    4 x USB 3.1 Gen 1
    4 x USB 2.0
    1 x Optical S/PDIF out
    1 x USB BIOS Flashback Button
    1 x 8-channel Audio I/O
    PCL Express
    2 x PCIe 3.0 x16 (x16 mode)
    2 x PCIe 3.0 x16 (Single at x16dual at x8/x8)
    1 x PCIe 3.0 x4 (x4 mode)
    LAN Dual GB LAN
    Buttons Clear CMOS , Reset , Power On , MemOk
    Package Weight 2.8000 kg
    Warranty 3 Years
    Condition New


    ASUS WS C422 PRO/SE LGA2066 ECC DDR4 M.2 U.2 C422 ATX Motherboard for Intel® Xeon® W-Series Processors with SafeSlot, Dual Gigabit LAN and USB 3.1 Type A / C

    • Designed for 7th generation LGA2066 socket Intel® W-Series processors with dual M.2, front panel USB 3.1 Gen2, Dual Intel® Gigabit LAN, support for ECC DDR4, Thunderbolt 3, Intel® VROC and Intel® Optane™ Memory compatibility
    • Next-gen transfer speeds with up to 32Gbps dual M.2 and U.2, plus up to 10Gbps USB 3.1 Type-A and Type-C connections
    • Patent-pending SafeSlot features an injection molding process that integrates metal framing for stronger, firmly anchored PCIe slots built for heavyweight GPUs, ideal for supporting 3-Way NVIDIA® SLI® or AMD® CrossfireX™
    • Industry-leading 8-channel HD audio enhanced by ASUS exclusive Realtek S1220A featuring Crystal Sound 3, DTS Headphone:X and driven by Japanese capacitors for warm, immersive sound
    • AURA Sync RGB lighting via Addressable RGB header features a nearly endless spectrum of colors with the ability to synchronize effects across an ever-expanding ecosystem of AURA Sync enabled products
    • Complete IT Infrastructure Management with ASMB9 Out-of-band remote management and In-band ASUS Control Center providing a complete server management solution reducing IT operating costs with features like remote BIOS updating, monitoring multiple systems via mobile device, and one-click software updates/dispatching.
    More Information
    Refurbished No
    Condition Brand New
