Asus PRIME X570-P, AMD X570, AM4, ATX, 4 DDR4, HDMI, XFire, PCIe4

£210.99

Out of stock

SKU

90MB11N0-M0EAY0

Skip to the end of the images gallery

Skip to the beginning of the images gallery

Add to Compare Add to Wish List

Key Features

Product Details:

Type	Desktop
Socket	AM4
Chipset	AMD X570
Maximum Memory	128GB
RAM Speed	AMD Ryzen series CPUs (Matisse) 4066+(OC)/3466(OC)/3200/2933/2667/2400/2133 AMD Ryzen series CPUs (Picasso) 3466+(OC)/3200(OC)/2933/ 2667/2400/2133
Memory Type	DDR4 (Dual Channel)
Storage	6 x SATA III 1 x M.2 (2242/2260/2280) - SATA & PCIe 1 x M.2 (2242/2260/2280/22110) - SATA & PCIe
PCI Express	Ryzen 3rd Gen CPUs: 1 x PCIe 4.0 x16 (x16 mode) Ryzen 2nd Gen CPUs: 1 x PCIe 3.0 x16 (x16 mode) Ryzen 1st/2nd Gen CPUs: 1 x PCIe 3.0 x16 (x8 mode) AMD X570 chipset 1 x PCIe 4.0 x16 (max at x4 mode) 3 x PCIe 4.0 x1
Graphics	MD Radeon Vega Series Graphics in Ryzen Series APU
Multi GPU Supports	Supports AMD 2-Way CrossFireX Technology
Graphics Port	1 x HDMI 1 x DisplayPort USB 1.2
Audio	Realtek S1200A 8-Channel High Definition Audio CODEC
USB Port Supports	USB 3.2 Gen2 Type-A 4 x USB 3.2 Gen1,7 x USB 2.0
Internal I/O connectors	2 x Aura RGB Strip 1 x Addressable Gen 2 2 x USB 2.0 2 x M.2 Socket 3 1 x SPI TPM 1 x COM port 6 x SATA 6Gb/s 1 x CPU Fan 3 x Chassis Fan 1 x PCH_FAN 1 x AIO_PUMP 1 x S/PDIF out 1 x 24-pin EATX 1 x 8-pin ATX 12V 1 x 4-pin ATX 12V 1 x Front audio connector(s) (AAFP) 1 x System panel 1 x Clear CMOS jumper 2 x USB 3.2 Gen 1
Back Panel I/o Ports	1 x PS/2 keyboard/mouse 1 x HDMI 1 x LAN (RJ45) 2 x USB 2.0 3 x Audio jacks 2 x USB 3.2 Gen 1 Type-A 4 x USB 3.2 Gen 2 Type-A
Wireless	Wi-Fi with MU-MIMO 802.11 a/b/g/n/ac Supports dual frequency band 2.4/5 GHz Up to 1.73Gbps transfer speed Bluetooth v5.0
LAN	Dual GB LAN
Accessories	User manual I/O Shield 2 x SATA 6Gb/s cable(s) 1 x M.2 Screw Package 1 x Supporting DVD 1 x Extension cable for Addressable LED
Package Weight	1.300 kg
Warranty	3 Years
Condition	New

Foundation of your build

Hosting the latest Ryzen processor with increased number of cores and bandwidth, the Prime X570 series is ready for action with stable power, intuitive cooling and flexible transfer options. It provides all the fundamentals to increase your everyday productivity.

Power delivery enhancements and ProCool connector

The latest AMD Ryzen 3rd Gen processors boosts more core and bandwidth, demanding more juice than typical desktop CPUs. Prime X570-P offers stable power. It augments the motherboard's link to the PSU with eight plus four-pin connectors that pass 12V power directly to the processors. Based on our ProCool design, these jacks use solid pins that can handle more current than hollow-pin connectors.

Tune it your way

The Prime X570 series feature software and firmware controls that make performance accessible to anyone. Prime X570 series also include options allowing you to personalise your build, and helping you to tune your rig to perform the way you want it.

Armoury Crate

Armoury Crate is a new software utility designed to give you centralised control of supported products. From a single intuitive interface, Armoury Crate allows you easily customise RGB lighting and effects for every compatible device in your arsenal. The software also provides control of settings for ASUS product, including keyboard and mouse preferences. Armoury Crate even features dedicated product registration and highlight to help you stay in touch with the ASUS community.

Aura Sync RGB headers

A well-tuned enthusiast system deserves a matching aesthetic. ASUS Aura Sync offers full lighting connected via the motherboard's RGB headers, with a variety of functional presets for external LED strips.* And it can all be synced with an ever-growing portfolio of Aura-capable ASUS hardware.

Addressable RGB LED strip Gen 2 header

The Prime X570-P now has the upgraded, addressable RGB header that allows intuitive software to control individual LEDs for more advanced effects and plenty of personalisation. The header is also ready for next-generation lighting devices, which can detect how many addressable LEDs are on an attached device, simplifying the setup process and allowing for automatically configured lighting effects.

Brighten Up Your Build

Built-in LED lighting options illuminate your build in a variety of eye-catching styles.

Enhanced power solution: Components provide better power efficiency
Industry-leading cooling options: Comprehensive controls for fans and AIO pump, via Fan Xpert 4 or the acclaimed UEFI
ASUS OptiMem: Careful routing of traces and vias to preserve signal integrity for improved memory overclocking
Next-gen connectivity: Supreme flexibility with PCIe Gen 4 support, dual M.2 support, USB 3.2 Gen 2 ports
Aura Sync RGB header: Synchronise RGB header with a vast portfolio of compatible PC gear, including next-gen addressable RGB strips
