Asrock X570M PRO4, AMD X570, AM4, Micro ATX, 4 DDR4, HDMI, DP, XFire, PCIe4, RGB Lighting, M.2

£239.99

Out of stock

SKU

X570M PRO4

Skip to the end of the images gallery

Skip to the beginning of the images gallery

Add to Compare Add to Wish List

Key Features

Product Details
Type	Desktop
Socket	AM4
Chipset	AMD X570
Maximum Memory	128GB DDR4
RAM Speed	Ryzen Matisse CPUs: 4200(OC) / 4133(OC) / 4000(OC) / 3866(OC) / 3800(OC) / 3733(OC) 3600(OC) / 3466(OC) / 3200/2933/2667/2400/2133 MHz Ryzen Pinnacle Ridge CPUs: 3466+(OC) / 3200(OC) / 2933/2667/2400/2133 MHz AMD Picasso CPUs: 3466+(OC) / 3200(OC) / 2933/2667/2400/2133 MHz
Memory Type	DDR4 (Dual Channel)
Storage	8 x SATA III 1 x Hyper M.2 (2242/2260/2280) - PCIe 1 x Hyper M.2 (2230/2242/2260/2280) - SATA & PCIe
Graphics	Integrated AMD Radeon R Series Graphics in the 7th Generation A-Series APU
Graphics Port	1 x DisplayPort 1.2 1 x HDMI
Multi GPU Support	Supports AMD CrossFireX Technology
Audio	Realtek ALC887-VD2 8-Channel High Definition Audio CODEC
USB Port Supported	4 x USB 3.1 Gen 1,2 x USB 3.1 Gen 2,2 x USB 3.1 Gen 16 x USB 2.0
M.2 Slots	Yes
Internal I/O connectors	1 x COM Port 1 x SPI TPM 1 x Power LED and Speaker 1 x AMD Fan LED 1 x RGB LED 1 x Addressable LED 1 x CPU Fan 1 x CPU/Water Pump Fan 3 x Chassis/Water Pump Fan 1 x 24 pin ATX 1 x 8 pin 12V 1 x Front Audio 1 x AMD LED Fan USB 1 x Thunderbolt AIC 2 x USB 2.0 1 x USB 3.2 Gen1
Back Panel I/o Ports	3 x Antenna 1 x PS/2 Mouse/Keyboard 1 x HDMI 1 x DisplayPort 1.2 1 x USB 3.2 Gen2 Type-A 1 x USB 3.2 Gen2 Type-C 6 x USB 3.2 Gen1 1 x RJ-45 LAN HD Audio Jacks
PCL Express	Ryzen Matisse CPUs: 2 x PCIe 4.0 x16 Ryzen Pinnacle Ridge CPUs: 2 x PCIe 3.0 x16 AMD Picasso CPUs: 2 x PCIe 3.0 x16 1 x PCIe 4.0 x1
LAN	GB LAN
Accessories	Users manual I/O Shield 2 x SATA Data Cables 3 x Screws for M.2 Sockets 1 x Standoff for M.2 Socke
Package Weight	1.4000 kg
Warranty	3 Years
Condition	New

Dual Hyper M.2 For SSD

Supports the next generation PCI Express 4.0 M.2 SSDs, it is capable of perform twice the speed compared to previous 3rd generation, giving a lightning fast data transferring experience.

Steel Slot with New Gen PCI-Express 4.0

The next generation PCI Express 4.0 is capable of performing twice the speed compared to previous 3rd generation. ASRock’s exclusive Steel Slot with extra anchor points are revolutionary added to ensure signal stability and also making sure heavy graphics cards to be well-installed in the PCI-E slot safely.

Dual USB 3.2 Gen2 (Type-A + Type-C)

This motherboard has a pair of onboard Type-A and Type-C USB 3.2 Gen2 ports built on the rear i/o for supporting next generation USB 3.2 Gen2 devices and to deliver up to 10 Gbps data transfer rates.

USB 3.2 Gen2 doubles the data transfer rate

USB 3.2 Gen2 Type-C doubles the charge speed!

Rule your own Lighting Way - Polychrome RGB

This motherboard features onboard RGB headers and an addressable RGB header that allow motherboard to be connected to compatible LED devices such as strip, CPU fans, coolers, chassis and so on. Users may also synchronize RGB LED devices across the Polychrome RGB Sync-certified accessories to create their own unique lighting effects.

Intel LAN

Intel LAN provides the best throughput performance, lower CPU utilization, enhanced stability and is able to deliver ultimate network experience to users!

Super Alloy Motherboard

XXL Aluminum Alloy Heatsink

Extra large aluminum alloy heat sinks that effectively take away heat from the MOSFET and chipset so that your whole system may perform more stable.

Premium 50A Power Choke

Compared to traditional chokes, ASRock’s premium 50A power chokes effectively make the saturation current up to three times better, thus providing enhanced and improved Vcore voltage to the motherboard.

Sapphire Black PCB

Pure black PCB appearance. The new Sapphire Black PCB represents rock-solid quality and gives the motherboard a more mysterious touch.

High Density Glass Fabric PCB

High Density Glass Fabric PCB design that reduces the gaps between the PCB layers to protect the motherboard against electrical shorts caused by humidity.

2oz Copper PCB

Using only carefully selected copper materials for PCB layers, 2oz Copper PCB delivers lower temperature and higher energy efficiency for overclocking.

M.2 (KEY E) For WiFi

Besides the onboard LAN port, users may also choose 802.11ac wireless connections by M.2 (Key E) slot.

*Wi-Fi module is not included.

ELNA Audio Caps

Who says high quality audio is only available on high-end motherboards? ASRock applied ELNA audio capacitors on mainstream and entry-level motherboards! Compared with traditional solid caps, the leakage current of ELNA audio caps is merely 3uA. This is the key to reduce noise level significantly and satisfy even the pickiest audiophiles.

Full Spike Protection

Some sensitive digital components on the motherboard are vulnerable to power surges, the excessive current may cause your system to malfunction immediately. ASRock Full Spike Protection includes various technologies to prevent your motherboard’s components from being damaged by these unexpected voltage spikes.

Live Update & APP Shop

ASRock Live Update & APP Shop is designed for your convenience. We provide various apps and support software for users to download. You can also easily optimize your system and keep your motherboard up to date with ASRock Live Update & APP Shop.
